IoT based Liquid level Monitoring using ESP32 board and Qubitro IoT Portal

 IoT based Liquid level Monitoring using ESP32 board and Qubitro IoT Portal

Hello Everyone! IoT based Liquid level Monitoring using ESP32 board and Qubitro IoT Portal In this video what you will learn about? 1. How to configure the new Qubitro Iot Platform. 2. How to Create new project on Qubitro IoT Platform. 4. How to Create Dashboard for Monitoring data. 5. How to Interface the Ultrasonic sensor with ESP32. 6. How to do the programming for the ESP32. #Qubitro #IoT

Circuit Diagram:

Code:

[Note :you need to install the QubitroMqttClient.h  library]

you can download the library click here Download

#include <QubitroMqttClient.h>

#include <WiFi.h>

#define trig 5   // Trig pin

#define echo 18

 int duration;

 int distance;

// WiFi Client

WiFiClient wifiClient;

// Qubitro Client

QubitroMqttClient mqttClient(wifiClient);

// Device Parameters

char deviceID[] = "5060befb-5aec-4777-b247-4c11ce884a54";

char deviceToken[] = "IeqcXR0zhmhHpbmf-mt8t1w$9FAg3-gutaMd-0$J";

// WiFi Parameters

const char* ssid = "impulsetech";

const char* password = "impulse567";

void setup() {

  // Initialize the serial port

  serial_init();



  // Initialize wireless connectivity

  wifi_init();

  // Initialize Qubitro

  qubitro_init();

  pinMode(trig, OUTPUT);

  pinMode(echo, INPUT);

}

void loop() {

  digitalWrite(trig, LOW);

  delayMicroseconds(2);

  digitalWrite(trig, HIGH);

  delayMicroseconds(10);

  digitalWrite(trig, LOW);

  duration = pulseIn(echo, HIGH);

  distance= duration*0.034/2;

  //Serial.println(distance);

  delay(100);

  // Generate random values

  int sensor_value_1 = distance;

  int sensor_value_2 = random(0, 100);

  // Print the random values

  Serial.print("Sensor value 1: ");

  Serial.println(sensor_value_1);

  Serial.print("Sensor value 2: ");

  Serial.println(sensor_value_2);

  // Send telemetry

  String payload = "{\"Sensor 1\":" + String(sensor_value_1)

    + ",\"Sensor 2\":" + String(sensor_value_2) + "}";

  mqttClient.poll();

  mqttClient.beginMessage(deviceID);

  mqttClient.print(payload);

  mqttClient.endMessage();

  // Delay

  delay(2000);

}

// Initialization code

void serial_init() {

  // Initiate serial port connection

  Serial.begin(115200);

  // Delay for stabilization

  delay(200);

}

void wifi_init() {

  // Set WiFi mode

  WiFi.mode(WIFI_STA);

  // Disconnect WiFi

  WiFi.disconnect();

  delay(100);

  // Initiate WiFi connection

  WiFi.begin(ssid, password);

  // Print connectivity status to the terminal

  Serial.print("Connecting to WiFi...");

  while(true)

  {

    delay(1000);

    Serial.print(".");

    if (WiFi.status() == WL_CONNECTED)

    {

      Serial.println("");

      Serial.println("WiFi Connected.");

      Serial.print("Local IP: ");

      Serial.println(WiFi.localIP());

      Serial.print("RSSI: ");

      Serial.println(WiFi.RSSI());

      break;

    }

  }

}

void qubitro_init() {

  char host[] = "broker.qubitro.com";

  int port = 1883;

  mqttClient.setId(deviceID);

  mqttClient.setDeviceIdToken(deviceID, deviceToken);

  Serial.println("Connecting to Qubitro...");

  if (!mqttClient.connect(host, port))

  {

    Serial.print("Connection failed. Error code: ");

    Serial.println(mqttClient.connectError());

    Serial.println("Visit docs.qubitro.com or create a new issue on github.com/qubitro");

  }

  Serial.println("Connected to Qubitro.");

  mqttClient.subscribe(deviceID);

}
